JOES Micro Sprint Front Axle Winged

AXLE SPECIFICATIONS:

Width

• 25650 – Wing Axle = 40.0″
• 25670 – Non-Wing Axle = 42.0″ (2″ longer right side)

Tube

• DIA – 1½” Chromoly Steel DOM
• CNC Machined to ensure repeatability in production

Spindle Boss / Kingpin

• CNC machined Spindle Boss
• Spindle Boss Diameter is 1⅛” x 2.080″ Height
• .625 Diameter Kingpin

Axle Geometry

• RT 12 Camber / 10 Caster
• LT  8 Camber / 7 Caster
• Designed for 10° Spindles

Radius Rod / Shock Mounts

• 10.5° angle
• Laser cut rectangular tube for strength
• TIG Welded in a CNC machined jig for consistency
